We export all these comments to an excel file to internally organize the derived tasks. In order to review the project, we have agreed with the client a reporting system through the Federated Model, where he can leave comments attached to different viewpoints.

allplan arquitectura

That way the client can use any IFC and BCF platform he desires to consult the information contained in the models. We have used Building Smart Open BIM standards. We have used Dynamo and programming in order to digitally fabricate some of the elements of the model, reducing the amount of time spent modeling. The relevant data of each BIM element was grouped under the “IDP_PARAMETERS” tab in order facilitate the search of parameters in the Model. We applied a Model nomenclature that let us discretize between the software used and its corresponding discipline through the acronyms contained in the linked models of the Federated Model. The data structure is crucial in any BIM project. The main Software used for that purpose has been ISTRAM, REVIT, TEKLA and ALLPLAN, among others. The Disciplines are: Road Design, Drainage, Structure, MEP, Vertical and Horizontal Signs of the Road. It’s a multidisciplinary project that has been modeled in different BIM Software platforms, depending on the nature of the elements. Not only because it was presented on the Smart City World Congress, also because walked the attendants through the reasons why the project is an example of what IDP considers SMART BIM: 1-Multidisciplinary and Cross-platform Coordination

allplan arquitectura

The title of the presentation was Smart BIM.

allplan arquitectura

The main structures of the projected branch due to the orographic difficulties of the terrain are: 2 tunnels of 155m and 335m, as well as 5 bridges with lengths between 90m and 130m. The extension of the C-32 from Tordera to Lloret de Mar has two main roads, on the one hand, the main road of the C-32 of 6.6 km, and on the other hand the road between the junction of Fanals and Papalús of 1 km. The motorway is located in the northeast of Catalonia crossing the coastal mountain range and runs parallel to the Mediterranean coast between the provinces of Barcelona and Girona, mainly affecting the municipalities of Tordera, Blanes and Lloret de Mar with a total distance of 122 km. On 20 November we presented the conference “SMART BIM: ROAD C32 CASE” at the SmartCatalonia agora, around the Smart City Expo World Congress 2019 held in Barcelona.ĭuring the session, the BIM model of the C-32 motorway extension construction project was presented.
